Tank Truck 465000-20 MAZ-6317X9

During production the inner surface of the Tank Truck 465000-20 MAZ-6317X9 of oval section is processed by zinc. Due to this, it shows wear resistance while transporting and storing oil products. It is characterized by carrying capacity - 16800 kg; MAZ tank truck volume - 20 m3; curb weight - 15 250 kg.

MAZ Tank Truck are made of metal alloy and are covered with several layers of paint to protect against corrosion. The inner zinc coating ensures durable operation even in contact with an aggressive environment. The locking elements prevent leakage of products from MAZ Tank Truck, besides they normalize the pressure for maximum safety of explosives transportation.

Additional elements

Upon customer's request the tank truck is upgraded by pumps, filters and other functional parts. It is used for transportation and storage of light oil products and in addition it can perform refuelling function.

Having bought truck tanks in Sespel Cheboksary enterprise CJSC, you will get a lot of advantages.

Main advantages of buying MAZ tank truck at Sespel

  • professional maintenance service in many cities of Russia;
  • components and spare parts from European companies optimal for use in Russia.

On page Contacts you can find the addresses and phone numbers of representative offices of our company in Moscow and other large cities of the Russian Federation: Ekaterinburg, St. Petersburg, Chelyabinsk, Nizhniy Novgorod, Rostov-on-Don and Kazan.

  • Specifications

Tank Truck 465000-20 MAZ-6317X9 - технические характеристики
Rated capacity, l 20000
Compartments 3
Total length, mm 9500
Height, mm 3940
Width, mm 2500
Wheel Base, mm 3690+1320
Axle configuration of the tractor 6x4
The distance between axes, mm 1320
Wheels 385/65 R22.5
Total gross weight, kg 33150
Vertical load on the fifth wheel, kg -
Axle load, kg 26000
Payload, kg 16800
Curb weight, kg 15250
More

Engineer consultation

Our engineers will help you calculate the optimal load on the road according to the RF Government Regulation No. 12 dated 01.05.2015 for your cargo and your tractor for operation without overloading and fines.
Axle load calculation
Select one of the standard configurations.
Or contact our specialists and choose your own configuration.
Tank Truck 465000-20 MAZ-6317X9 - ЗАО «Сеспель»
