АЦ RS4319 SCANIA P380B8
Specifications
| Rated capacity, l | 19000 |
| Compartments | 3 (4,0; 7,5; 7,5) |
| Total length, mm | 10100 |
| Height, mm | 4000 |
| Width, mm | 2550 |
| Wheel Base, mm | 1990х3560х1350 |
| The distance between axes, mm | 1350 |
| Total gross weight, kg | 37000 |
| Vertical load on the fifth wheel, kg | 16000 |
| Axle load, kg | 21000 |
| Payload, kg | 16000 |
| Curb weight, kg | 14700 |
|
More
|
|
Engineer consultation
Our engineers will help you calculate the optimal load on the road according to the RF Government Regulation No. 12 dated 01.05.2015 for your cargo and your tractor for operation without overloading and fines.
Select one of the standard configurations.
Or contact our specialists and choose your own configuration.
|
Order
RS4319_3S_01, 19 m3, 2 compartment
|
If you have an individual project, please, fill out the data input form and send it to us for calculation.
Download the questionnaire
