46523-2, SCANIA-P400, 4 compartments

  • Specifications

Model 46523-2, SCANIA-P400, 4 отсека
Rated capacity, l 23000
Total length, mm 9393
Height, mm 4000
Width, mm 2500
Wheel Base, mm 1940+2960+1350
The distance between axes, mm 1350
Total gross weight, kg 36000
Vertical load on the fifth wheel, kg 7960
Axle load, kg 21000
Payload, kg 12740
Axle configuration of the tractor 6x4
Number of compartments 4
Curb weight, kg 14500
Recovery No
Material Steel
Meter Yes
Access box position On the left side
Pump Yes
Discharge assembly On the left side

Engineer consultation

Our engineers will help you calculate the optimal load on the road according to the RF Government Regulation No. 12 dated 01.05.2015 for your cargo and your tractor for operation without overloading and fines.
