SF3B25

Sespel company sells bitumen tankers of its own production. The tanks for dark oil products (bitumen, fuel oil) SF3B25 from Sespel released in 2013 are optimal for storage and transport of bitumen and oil products with density up to 1,0 ton/m3. It is allowed to transport hot substances which temperature reaches 200 degrees. The tank capacity is 25 cub.m. The dimensions are 10,6х3,5х2,5 m, this provides good cross-country ability on Russian roads when transporting products from oil tank farms to enterprises or direct consumers.

For the manufacture of bitumen tanker low alloy steel 09G2S is used. The body is covered with thermal insulation and galvanized steel sheet. During production the strength and tightness of the tank for transportation of dark petroleum products (bitumen, fuel oil) is checked by experts, thanks to which the equipment has safety excellence and is environmentally safe.

Tanks for dark oil products transportation  (bitumen, fuel oil): design features

The bitumen tanker  has a total weight of 32,4 tons and its carrying capacity is 25 tons. The machinery is fitted with BPW axle, WABCO brake system, thereby ensuring the reliability of the movement of the tank for dark oil products (bitumen, fuel oil) on the roads, even with non-ideal asphalt covering. The tanks for bitumen transportation tanks for bitumen transportation with 30,000 kg. payload are also available at Sespel company.

The network of sales offices of Sespel company is extended to all major cities of the country. Among them are Moscow and Yekaterinburg, Chelyabinsk and St. Petersburg, Kazan, Nizhny Novgorod and Rostov-on-Don. Please, go to page Contacts to get their addresses.

European components in Cheboksary towed machinery, professional service from  Sespel professionals ensure complete reliability and efficiency while using each tank for dark oil products (bitumen, fuel oil).

  • Specifications

SF3B25 - технические характеристики
Rated capacity, l 25000
Total length, mm 10600
Height, mm 3500
Width, mm 2500
Wheel Base, mm 5230 +1360+1360
The distance between axes, mm 1360
Wheels 385/65R22,5; 6+1
Total gross weight, kg 32400
Vertical load on the fifth wheel, kg 11200
Axle load, kg 21200
Payload, kg 25000
Curb weight, kg 7123
More

Engineer consultation

Our engineers will help you calculate the optimal load on the road according to the RF Government Regulation No. 12 dated 01.05.2015 for your cargo and your tractor for operation without overloading and fines.
Axle load calculation
Select one of the standard configurations.
Or contact our specialists and choose your own configuration.
  • The Tank semitrailer SF3B25_1S_19, fifth-wheel 1150, 25 m3, 1 compartment is made from low-alloy steel.
  • The total capacity is 25 m3 with division into 1 compartment.
  • Three-axle single-wheeled air suspension manufactured by BPW (Germany), the warranty is provided by BPW for up to 3 years.
  • The total mass of the semitrailer is 32000 kg.
  • Double circuit brake system WABCO, equipped with TEBS (2S / 2M) with Roll Stability Support function.
  • The semitrailer is equipped with PVC fenders.
  • The fifth wheel height is from 1150 to 1250 mm.
SF3B25_1S_19, fifth-wheel 1150, 25 m3, 1 compartment - ЗАО «Сеспель»
Order
  • The Tank semitrailer SF3B25_1S_18, fifth-wheel 1350, 25 m3, 1 compartment is made from low-alloy steel.
  • The total capacity is 25 m3 with division into 1 compartment.
  • Three-axle single-wheeled air suspension manufactured by BPW (Germany), the warranty is provided by BPW for up to 3 years.
  • The total mass of the semitrailer is 32400 kg.
  • Double circuit brake system WABCO, equipped with TEBS (2S / 2M) with Roll Stability Support function.
  • The semitrailer is equipped with PVC fenders.
  • The fifth wheel height is from 1250 to 1350 mm.
SF3B25_1S_18, fifth-wheel 1350, 25 m3, 1 compartment - ЗАО «Сеспель»
Order
  • The Tank semitrailer SF3B25_1S_17, fifth-wheel 1350, 25 m3, 1 compartment is made from low-alloy steel.
  • The total capacity is 25 m3 with division into 1 compartment.
  • Three-axle single-wheeled air suspension manufactured by BPW (Germany), the warranty is provided by BPW for up to 3 years.
  • The total mass of the semitrailer is 32500 kg.
  • Double circuit brake system WABCO, equipped with TEBS (2S / 2M) with Roll Stability Support function.
  • The semitrailer is equipped with PVC fenders.
  • The fifth wheel height is from 1250 to 1350 mm.
SF3B25_1S_17, fifth-wheel 1350, 25 m3, 1 compartment - ЗАО «Сеспель»
Order
  • The Tank semitrailer SF3B25_1S_16, fifth-wheel 1250, 25 m3, 1 compartment is made from low-alloy steel.
  • The total capacity is 25 m3 with division into 1 compartment.
  • Three-axle single-wheeled air suspension manufactured by BPW (Germany), the warranty is provided by BPW for up to 3 years.
  • The total mass of the semitrailer is 32425 kg.
  • Double circuit brake system WABCO, equipped with TEBS (2S / 2M) with Roll Stability Support function.
  • The semitrailer is equipped with PVC fenders.
  • The fifth wheel height is from 1150 to 1250 mm.
SF3B25_1S_16, fifth-wheel 1250, 25 m3, 1 compartment - ЗАО «Сеспель»
Order
  • The Tank semitrailer SF3B25_1S_15, fifth-wheel 1250, 25 m3, 1 compartment is made from low-alloy steel.
  • The total capacity is 25 m3 with division into 1 compartment.
  • Three-axle single-wheeled air suspension manufactured by BPW (Germany), the warranty is provided by BPW for up to 3 years.
  • The total mass of the semitrailer is 32550 kg.
  • Double circuit brake system WABCO, equipped with TEBS (2S / 2M) with Roll Stability Support function.
  • The semitrailer is equipped with PVC fenders.
  • The fifth wheel height is from 1150 to 1250 mm.
SF3B25_1S_15, fifth-wheel 1250, 25 m3, 1 compartment - ЗАО «Сеспель»
Order
  • The Tank semitrailer SF3B25_1S_14, fifth-wheel 1150, 25 m3, 1 compartment is made from low-alloy steel.
  • The total capacity is 25 m3 with division into 1 compartment.
  • Three-axle single-wheeled air suspension manufactured by BPW (Germany), the warranty is provided by BPW for up to 3 years.
  • The total mass of the semitrailer is 32100 kg.
  • Double circuit brake system WABCO, equipped with TEBS (2S / 2M) with Roll Stability Support function.
  • The semitrailer is equipped with PVC fenders.
  • The fifth wheel height is from 1150 to 1250 mm.
SF3B25_1S_14, fifth-wheel 1150, 25 m3, 1 compartment - ЗАО «Сеспель»
Order
  • The Tank semitrailer SF3B25_1S_13, fifth-wheel 1250, 25 m3, 1 compartment is made from low-alloy steel.
  • The total capacity is 25 m3 with division into 1 compartment.
  • Three-axle single-wheeled air suspension manufactured by BPW (Germany), the warranty is provided by BPW for up to 3 years.
  • The total mass of the semitrailer is 32200 kg.
  • Double circuit brake system WABCO, equipped with TEBS (2S / 2M) with Roll Stability Support function.
  • The semitrailer is equipped with PVC fenders.
  • The fifth wheel height is from 1150 to 1250 mm.
SF3B25_1S_13, fifth-wheel 1250, 25 m3, 1 compartment - ЗАО «Сеспель»
Order
  • The Tank semitrailer SF3B25_1S_12, fifth-wheel 1250, 25 m3, 1 compartment is made from low-alloy steel.
  • The total capacity is 25 m3 with division into 1 compartment.
  • Three-axle single-wheeled air suspension manufactured by BPW (Germany), the warranty is provided by BPW for up to 3 years.
  • The total mass of the semitrailer is 31000 kg.
  • Double circuit brake system WABCO, equipped with TEBS (2S / 2M) with Roll Stability Support function.
  • The semitrailer is equipped with PVC fenders.
  • The fifth wheel height is from 1150 to 1250 mm.
SF3B25_1S_12, fifth-wheel 1250, 25 m3, 1 compartment - ЗАО «Сеспель»
Order
  • The Tank semitrailer SF3B25_1S_04, fifth-wheel 1350, 25 m3, 1 compartment is made from low-alloy steel.
  • The total capacity is 25 m3 with division into 1 compartment.
  • Three-axle single-wheeled air suspension manufactured by BPW (Germany), the warranty is provided by BPW for up to 3 years.
  • The total mass of the semitrailer is 31000 kg.
  • Double circuit brake system WABCO, equipped with TEBS (2S / 2M) with Roll Stability Support function.
  • The semitrailer is equipped with PVC fenders.
  • The fifth wheel height is from 1250 to 1350 mm.
SF3B25_1S_04, fifth-wheel 1350, 25 m3, 1 compartment - ЗАО «Сеспель»
Order
  • The Tank semitrailer SF3B25_1S_05, fifth-wheel 1350, 25 m3, 1 compartment is made from low-alloy steel.
  • The total capacity is 25 m3 with division into 1 compartment.
  • Three-axle single-wheeled air suspension manufactured by BPW (Germany), the warranty is provided by BPW for up to 3 years.
  • The total mass of the semitrailer is 31400 kg.
  • Double circuit brake system WABCO, equipped with TEBS (2S / 2M) with Roll Stability Support function.
  • The semitrailer is equipped with PVC fenders.
  • The fifth wheel height is from 1250 to 1350 mm.
SF3B25_1S_05, fifth-wheel 1350, 25 m3, 1 compartment - ЗАО «Сеспель»
Order
  • The Tank semitrailer SF3B25_1S_06, fifth-wheel 1250, 25 m3, 1 compartment is made from low-alloy steel.
  • The total capacity is 25 m3 with division into 1 compartment.
  • Three-axle single-wheeled air suspension manufactured by BPW (Germany), the warranty is provided by BPW for up to 3 years.
  • The total mass of the semitrailer is 31000 kg.
  • Double circuit brake system WABCO, equipped with TEBS (2S / 2M) with Roll Stability Support function.
  • The semitrailer is equipped with PVC fenders.
  • The fifth wheel height is from 1150 to 1250 mm.
SF3B25_1S_06, fifth-wheel 1250, 25 m3, 1 compartment - ЗАО «Сеспель»
Order
  • The Tank semitrailer SF3B25_1S_07, fifth-wheel 1250, 25 m3, 1 compartment is made from low-alloy steel.
  • The total capacity is 25 m3 with division into 1 compartment.
  • Three-axle single-wheeled air suspension manufactured by BPW (Germany), the warranty is provided by BPW for up to 3 years.
  • The total mass of the semitrailer is 31000 kg.
  • Double circuit brake system WABCO, equipped with TEBS (2S / 2M) with Roll Stability Support function.
  • The semitrailer is equipped with PVC fenders.
  • The fifth wheel height is from 1150 to 1250 mm.
SF3B25_1S_07, fifth-wheel 1250, 25 m3, 1 compartment - ЗАО «Сеспель»
Order
  • The Tank semitrailer SF3B25_1S_08, fifth-wheel 1250, 25 m3, 1 compartment is made from low-alloy steel.
  • The total capacity is 25 m3 with division into 1 compartment.
  • Three-axle single-wheeled air suspension manufactured by BPW (Germany), the warranty is provided by BPW for up to 3 years.
  • The total mass of the semitrailer is 31100 kg.
  • Double circuit brake system WABCO, equipped with TEBS (2S / 2M) with Roll Stability Support function.
  • The semitrailer is equipped with PVC fenders.
  • The fifth wheel height is from 1150 to 1250 mm.
SF3B25_1S_08, fifth-wheel 1250, 25 m3, 1 compartment  - ЗАО «Сеспель»
Order
  • The Tank semitrailer SF3B25_1S_09, fifth-wheel 1350, 25 m3, 1 compartment is made from low-alloy steel.
  • The total capacity is 25 m3 with division into 1 compartment.
  • Three-axle single-wheeled air suspension manufactured by BPW (Germany), the warranty is provided by BPW for up to 3 years.
  • The total mass of the semitrailer is 31740 kg.
  • Double circuit brake system WABCO, equipped with TEBS (2S / 2M) with Roll Stability Support function.
  • The semitrailer is equipped with PVC fenders.
  • The fifth wheel height is from 1250 to 1350 mm.
SF3B25_1S_09, fifth-wheel 1350, 25 m3, 1 compartment - ЗАО «Сеспель»
Order
  • The Tank semitrailer SF3B25_1S_10, fifth-wheel 1250, 25 m3, 1 compartment is made from low-alloy steel.
  • The total capacity is 25 m3 with division into 1 compartment.
  • Three-axle single-wheeled air suspension manufactured by BPW (Germany), the warranty is provided by BPW for up to 3 years.
  • The total mass of the semitrailer is 31300 kg.
  • Double circuit brake system WABCO, equipped with TEBS (2S / 2M) with Roll Stability Support function.
  • The semitrailer is equipped with PVC fenders.
  • The fifth wheel height is from 1150 to 1250 mm.
SF3B25_1S_10, fifth-wheel 1250, 25 m3, 1 compartment - ЗАО «Сеспель»
Order
If you have an individual project, please, fill out the data input form and send it to us for calculation.
