DB4U60_1A_998, 60 m3, fifth-wheel 1250
Specifications
| Model | DB4U60_1A_998 |
| Rated capacity, l | 60000 |
| Total length, mm | 14018 |
| Height, mm | 3445 |
| Width, mm | 2550 |
| Wheel Base, mm | 6615+1310+1310+1310 |
| The distance between axes, mm | 1310 |
| Total gross weight, kg | 36000 |
| Vertical load on the fifth wheel, kg | 10000 |
| Axle load, kg | 26000 |
| Payload, kg | 28250 |
| Axle configuration of the tractor | 4x2 |
| Curb weight, kg | 7750 |
| Axles | Sespel |
| Fifth wheel height, mm | 1250 |
| Material | Aluminum |
| Discharge assembly | On the rear side |
|
More
|
|
Engineer consultation
Our engineers will help you calculate the optimal load on the road according to the RF Government Regulation No. 12 dated 01.05.2015 for your cargo and your tractor for operation without overloading and fines.
