SB4U53_1A_01, 53 m3, 1 compartment, fifth-wheel 1150

  • Specifications

SB4U53_1A_01, 53 m3, 1 compartment, fifth-wheel 1150 - технические характеристики
Model SB4U53_1A_01
Rated capacity, l 53000
Total length, mm 12110
Height, mm 4000
Width, mm 2550
Wheel Base, mm 4430+1310+1310+1310
The distance between axes, mm 1310
Wheels 385/65R22,5; 8+1
Total gross weight, kg 35300
Vertical load on the fifth wheel, kg 9300
Axle load, kg 26000
Payload, kg 27700
Axle configuration of the tractor 4x2
Number of compartments 1
Curb weight, kg 7600
Axles BPW
Fifth wheel height, mm 1150
Material Aluminum
Access box position On the rear side
Mounting area for compressor Yes
Discharge assembly On the rear side

Engineer consultation

Our engineers will help you calculate the optimal load on the road according to the RF Government Regulation No. 12 dated 01.05.2015 for your cargo and your tractor for operation without overloading and fines.
